Electro-Optics
NIGHT WATCHER M25
High-Performance Low-Cost Night Vision System
The NIGHT WATCHER M25 is a high-performance, low-cost Night Vision System incorporating a 95mm Catadioptic Objective Lens and a 25mm 2nd Generation Image Intensifier, which is interchangeable with a 3rd Gen drop-in replacement. Ideally suitable for Law Enforcement, Border Control, Anti-Drug Operations, Animal Conservation, and similar tactical duties.
Technical Specifications
Mechanical Specifications
| Overall Length | 280mm (inc. OLC & eyeguard) |
| Maximum Height | 112mm |
| Maximum Width | 90mm |
| Weight | 1.8 Kg |
| Construction | Aluminium, hard black anodized (Optional Black Teflon finish) |
| Environment | Commercial |
Optical Specifications
| Objective Lens | 95mm F/1.2 Catadioptic |
| Field of View | 14.5 degrees (253 mr) |
| Focus | 10m to Infinity |
| Ocular Lens | 25mm (Fixed at -1.75 diopters) |
| System Magnification | x3.8 |
| Range (Man-sized target) | 335m (Starlight) |
Electrical Specifications
| Image Intensifier | 25mm 2nd Generation MCP with AGC & BSP |
| Tube Gain | 45,000 typical |
| Tube Resolution | 28 lp/mm |
| External Control | Combined rotary switch On/Off & Gain |
| Power Source | 3.0 Lithium Battery (CR123A) |
| Operational Duration | Approx. 30 hours |
Standard Supply Package
High Impact Carrying Case
Operator’s Manual
Lens Brush & Tissues
Objective Lens Cap / Daylight Training Filter
Open Eyeguard
Lithium Batteries (x2)
Modular Accessories & Optional Extras
3rd Gen Drop-in replacement Intensifier
155mm Catadioptic Objective Lens
High performance Objective Lenses
Biocular Lens (Permits viewing with both eyes)
Objective Lens Mount Adapters (For Photo Lenses)
Relay Lenses for CCTV or 35mm SLR Cameras
Pistol Grip
Solid State Laser Illuminators
Hostile Filters for 95mm & 155mm Objective Lenses
Secured Eyeguard
